120W 12Vdc Single Output Switching LED Power Supply, GL Power, TÜV
34.00 VAT excl.
£40.80 VAT incl.
120W 12Vdc Single Output Switching LED Power Supply, GL Power, TÜV certificate
- Suitable for LED lighting
- Universal AC input
- Constant voltage design: 12Vdc
- Fully encapsulated with IP67 level
You can order online 24/7, all ordered goods will be dispatched as soon as possible and we will notify you via e-mail. For custom made orders please contact us.
Orders over £500 (excl. VAT) Standard and Next Day service apply to UK mainland and Northern Ireland only. All orders will be sent by a trackable method.
You have the right to cancel your online website order within 14 calendar working days of ordering, or 14 calendar days of receipt of the goods (whichever is the longer).
120W 12Vdc Single Output Switching LED Power Supply, GL Power, TÜV certificate
Model: GPV-150-12
Output:
LED driver mode: constant voltage
Output Voltage: 12Vdc
No of outputs: 1
Output Voltage: 12Vdc
No of outputs: 1
Rated current: 10A
Current range: 0-10A
Rated power: 120W
Line regulation: ± 1%
Load regulation: ± 2%
Voltage tolerance: ± 5%
Ripple & noise (max.): 200mVP-P
Setup, rise time: 500ms, 50ms / 230VAC
Hold up time (typ.): 18ms / 230VAC
Rated power: 120W
Line regulation: ± 1%
Load regulation: ± 2%
Voltage tolerance: ± 5%
Ripple & noise (max.): 200mVP-P
Setup, rise time: 500ms, 50ms / 230VAC
Hold up time (typ.): 18ms / 230VAC
Input:
Input Voltage: 180 ÷ 277VAC
Frequency range: 47 ÷ 63Hz
Efficiency: 87%
AC current (typ.): 1.7A / 230VAC, 1.5A / 277VAC
Input Voltage: 180 ÷ 277VAC
Frequency range: 47 ÷ 63Hz
Efficiency: 87%
AC current (typ.): 1.7A / 230VAC, 1.5A / 277VAC
Inrush current (typ.): 60A / 230VAC
Leakage current(max.): 0.25mA / 240VAC
Leakage current(max.): 0.25mA / 240VAC
Protections:
Overcurrent:
- range: 110 ÷ 150%
- type: hiccup mode, auto-recovery
Overcurrent:
- range: 110 ÷ 150%
- type: hiccup mode, auto-recovery
Short circuit:
- type: hiccup mode, auto-recovery
Over voltage:
Over voltage:
- 13.5 ÷ 18V
- type: hiccup mode, auto-recovery
Over temperature:
- range: 110°C ± 10°C
- type: shut down output voltage. After temperature goes down re-power on to recovery.
Over temperature:
- range: 110°C ± 10°C
- type: shut down output voltage. After temperature goes down re-power on to recovery.
Environment:
Working temperature: -30°C ÷ 70°C (Refer to Derating Curve)
Working humidity: 20 ÷ 90% RH non-condensing
Storage temperature and humidity: -40°C ÷ 80°C, 10 ÷ 95% RH non-condensing
Temperature coefficient: ± 0.03% / °C (0°C ÷ 50°C)
Vibration: 10 ÷ 500Hz, 5G, 12min / cycle, period for 72min. each along X, Y, Z axes
Working humidity: 20 ÷ 90% RH non-condensing
Storage temperature and humidity: -40°C ÷ 80°C, 10 ÷ 95% RH non-condensing
Temperature coefficient: ± 0.03% / °C (0°C ÷ 50°C)
Vibration: 10 ÷ 500Hz, 5G, 12min / cycle, period for 72min. each along X, Y, Z axes
Safety and EMC regulations:
Safety standards: compliance to EN61347-1, EN61347-2-13, IP67
Withstand voltage: I-P/O-P: 3kVAC
Isolation resistance: I-P/O-P: 100MΩ/500VDC/25°C/70%
EMC emission: compliance to EN55015
EMC immunity: compliance to EN61547; EN55024; EN61000-4-2, -3, -4, -5, -6, -8, -11
Harmonic current: compliance to EN61000-3-3; EN61000-3-2
TÜV certificate
Safety standards: compliance to EN61347-1, EN61347-2-13, IP67
Withstand voltage: I-P/O-P: 3kVAC
Isolation resistance: I-P/O-P: 100MΩ/500VDC/25°C/70%
EMC emission: compliance to EN55015
EMC immunity: compliance to EN61547; EN55024; EN61000-4-2, -3, -4, -5, -6, -8, -11
Harmonic current: compliance to EN61000-3-3; EN61000-3-2
TÜV certificate
Other:
Dimensions: 203 x 70 x 45mm (L x W x H)
Weight: 1.15kg
Termination style: flying leads, approx. 300mm ± 30mm (input:2 x 0.75mm2; output: 2 x 1.5mm2)
IP67
GPV-150-12
100 Items
Data sheet
- Type
- Constant Voltage
- Ingress Protection (IP)
- IP67
- Output
- 12VDC
- Wattage
- 120W
- Dimming Control
- Non-dimmable
- Design
- Plastic case
